Starting at $6,000
HDMS800-lite is an integrated full HD (1080p) auto focus digital microscope and measurement system that operates without a PC. It incorporates different sets of inspection and measurement applications such as focus stacking, 2D measurement, side by side and overlay image comparison, custom on screen reticule/graticule and lens distortion correction.
The HDMS800-lite auto focus digital microscope has a powerful image processing and control engine that delivers full HD live video at 60 frames per second. It could be used as a solution for quality control, testing, rework, assembly, inspection and documentation tasks. A clean and easy designed GUI (Graphical User Interface) controlling by a mouse delivering efficient operation and fully control the application.
HDMS800-lite has a special feature separate from other digital inspection systems. HDMS800-lite has the ability to stay in calibration over the entire zoom range. The HDMS800-lite Camera has control functions (auto and manual focus, exposure, gain, brightness, white balance) ensure ultrasharp, high contrast imaging.
Click for PDF of different HDMS800 models and options
HDMS800-lite Key Features
- Focus Stacking
- Image Overlay Comparator
- Side by Side Image Comparison
- Lens Distortion Correction
- Removable USB Image Capture
- Save and Recall Images Internally
- Transfer Images to PC via USB
- Intuitive GUI
- No PC Required
**HDMS800-lite can later be upgraded to include 2D measurement & annotation, on-screen reticule graticule, and calibration tracking functions (NOTE: these features are included in HDMS800 system).
Customizable Platform
The HDMS800 platform can be customized for your application needs. The platform will include these features as the core apps…
- Intuitive Interface: Intuitive mouse and keyboard GUI for simple and familiar user experience
- Email: Save time by emailing directly from the HDMS800. Document directly to server or cloud network for traceability
- User Privileges: User privileges settings enable operational control and traceability
- Lens Distortion Correction: Lens distortion is inherent in all microscopes. For large samples, distortion at the outer edges of the images can be corrected to enable larger field of view.
- Networking: Networking enables direct saving to the server or cloud for increased workflow efficiency
- Internal & External Storage: USB and internal storage of images or graticule files for off network saving
..and depending on your needs, you can add these additional apps:
**HDMS800-lite can later be upgraded to include 2D measurement & annotation, on-screen reticule graticule, and calibration tracking functions (NOTE: these features are included in HDMS800 system).
DXF Import
Import a range of DXF files to create graticules for overlay comparison with parts. Imported DXF files can be edited and annotated on the HDMS800 system. This dramatically reduces time taken to create graticules and increases workflow efficiency.
Image Stacking
The HDMS800-lite is able to sample from up to 12 images with different focal depths and stack the sharpest sections of each image sample to create one completely in-focus image.
Comparator Overlay and Comparator Side by Side
Image comparison can be done in one of two ways. Overlay comparison allows the user to spot defects by flashing between the live image and stored image. Side by side comparison allows the user to view both the live image and stored image simultaneously via split screen viewing. The viewing ratio of the comparison can be adjusted according to the user’s needs and even saved with annotation for documentation.
User Efficiency
**HDMS800-lite can later be upgraded to include 2D measurement & annotation, on-screen reticule graticule, and calibration tracking functions (NOTE: these features are included in HDMS800 system).
Optional 360° Rotating Viewer
The 360° Rotating Viewer can be used with the HDMS800 digital microscope system, allowing users to rapidly inspect samples from an oblique angle (28⁰ from vertical).
By simply rotating the viewer, the user can inspect any sample from multiple angles. Users can easily switch from 360⁰ view to normal view with the adjustable mirror.
The 360° Rotating Viewer is useful in bare PCB inspection, solder joint inspection on assembled PCBs, electronics, quality control inspection, inspection of tips of small bore medical cylindrical parts, medical device manufacturing, and metal-cutting Tools.
Applications
With a clean and easy-to-use interface, the HDMS800-lite is ideal for individual inspection measurements and documentation as well as group viewing and training purposes.
Specifications
| Magnification* | ||||||||||
| Lens (Dioptre) (mm) | Maximum Height (mm) | Minimum Height | Minimum Magnification* | Maximum Magnification* (Optical/Digital) | Field of View at min. magnification (mm) | Field of View at max. magnification (mm) Optical/Digital | Max. and Min. Depth of Field (mm) | |||
| 5 | 200 | 170 | 2.5 | 62/122 | X: 231 | Y: 136 | X: 8/4 | Y: 5/2 | 78 | .50 |
| 10 | 100 | 85 | 4 | 121/237 | X: 60 | Y: 50 | X: 5/2 | Y: 3/1 | 57 | .20 |
| *Specifications obtained using a 24" monitor *Depth of field measured with optimal image settings | ||||||||||
| Technical Specifications | |
| Zoom Range (with supplied 5D lens) | 2.5x-122x |
| Camera Resolution | 1920x1080 Resolution | 60 fps | 30x Optical, 2x Digital |
| Monitor Connections | HDMI/DVI |
| Monitor Requirements | HD Ready or Full HD (recommended) |
| Input/Output | HDMI Output USB 2.0 Port x4 RJ45 Ethernet Connector (for networking) General Purpose IO Port x3 DC Power Jack (24V) |
| Image Capture | Internal Image Storage Removable USB Image Storage USB On the Go (PC Connectivity) |
| Power | 24W |
| Dimensions | 216mm x 125mm x 136mm |
| Weight | 1.75Kg |
| Operating Temperatures | Storage: -10C to +60C Operating: +5C to 40C |
Click for PDF of different HDMS800 models and options
Image Gallery – Measurement Tool Upgrade Examples (click to enlarge)
